ASUS ROG Maximus XIII Extreme
LGA 1200, Intel Z590, E-ATXCurrently out of stock
Product details
ASUS Z590 series motherboards are designed to squeeze every ounce of performance out of 11th generation Intel Core processors. Updated power supply designs underpin the entire range, which is enhanced
by connectivity options and expanded with refined features that use artificial intelligence to put advanced performance at your fingertips.ASUS Z590 motherboards feature exclusive software and firmware utilities that use machine learning and artificial intelligence (AI) to improve the user experience. On select motherboard models, ASUS AI enhancements include four distinct performance pillars: Overclocking, Cooling, Networking and even Onboard Audio. This makes advanced optimisations and tweaks more accessible to both staff and savvy PC home improvement veterans.To ensure system stability under heavy CPU workloads, ASUS Z590 motherboards use large VRM and chipset heatsinks that strike the right balance between surface area and mass. The same philosophy applies to integrated M.2 heatsinks to ensure readiness for the next wave of PCIe 4.0 SSDs.
| Processor family | Celeron, Core i3 10th Gen, Core i5 10th Gen, Core i7 10th Gen, Core i9 10th Gen, Pentium |
| Memory type | DDR4-RAM |
| Internal connection options | M.2 SATA (5x), S-ATA III (6x) |
| Wireless transmission | Wi-Fi |
| Peripheral connections | USB 2.0 Type-A (2x), USB 3.2 Gen 1 (2x), USB 3.2 Gen 2 (8x) |
| Item number | 14723049 |
| Manufacturer | |
| Category | |
| Manufacturer no. | 90MB15S0-M0EAY0 |
| Release date | 19.1.2021 |
| Form factor | E-ATX |
| Processor socket | LGA 1200 |
| Chipset | Intel Z590 |
| Mainboard features | Clear CMOS Button |
| Operating system compatibility | Windows 10 |
| Peripheral connections | USB 2.0 Type-A (2x), USB 3.2 Gen 1 (2x), USB 3.2 Gen 2 (8x) |
| BIOS type | UEFI AMI |
| Wireless transmission | Wi-Fi |
| Wi-Fi standard | Wi-Fi 6 / 802.11ax |
| Processor type | Intel Core i7 |
| Processor clock frequency | 5333 MHz |
| Processor family | Celeron, Core i3 10th Gen, Core i5 10th Gen, Core i7 10th Gen, Core i9 10th Gen, Pentium |
| Memory form factor | DIMM |
| Number of pins | 288 x |
| Number of memory modules (RAM) | 4 x |
| Max. memory (RAM) | 128 GB |
| Memory chip | DDR4-3200 |
| Max. RAM OC | 5333 MHz |
| Supported memory speed | 2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3200 MHz |
| Memory type | DDR4-RAM |
| RAM buffer | Unbuffered |
| Video connections | HDMI (1x) |
| Multi-GPU technology | NVIDIA SLI |
| Network connections | RJ45 10 Gigabit Ethernet (1x), RJ45 2.5 Gigabit Ethernet (1x) |
| Ethernet controller brand | Intel |
| Ethernet controller | Intel I225-V |
| Max. port speed | 10 Gbit/s |
| Chip | Realtek ALC4082 |
| Audio channel | 7.1 Channel |
| Internal connection options | M.2 SATA (5x), S-ATA III (6x) |
| Expansion slot | PCI Express x16 (3x) |
| PCI express version (max.) | 4 |
| Number of fan connector | 2 |
| Power connectors | 24-pin ATX, 6-pin PCI-E, 8-pin ATX 12V |
| Scope of delivery | 3 x Serial ATA cable |
| Length | 277 mm |
| Width | 305 mm |
| Height | 277 mm |
| Weight | 5340 g |
| Length | 32 cm |
| Width | 13 cm |
| Height | 38 cm |
| Weight | 4.98 kg |
Specifications may include unverified machine translations.
Reviews & Ratings
Warranty score
How often does a product of this brand in the «Motherboards» category have a defect within the first 24 months?
Source: Digitec Galaxus- 1.MSI2.7 %
- 3.AsRock2.8 %
- 4.ASUS2.9 %
- 5.NZXT4.9 %
- 6.Biostar5.7 %
Warranty case duration
How many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: Digitec Galaxus- 1.MSI2 days
- 1.NZXT2 days
- 5.ASUS4 days
- 5.Supermicro4 days
- 7.Biostar5 days
Return rate
How often is a product of this brand in the «Motherboards» category returned?
Source: Digitec Galaxus- 1.MSI4.5 %
- 2.Gigabyte4.8 %
- 3.ASUS4.9 %
- 4.Supermicro5 %
- 5.NZXT6.1 %
Source: Digitec Galaxus
Translation: machine translated
Very good90/100
- High-quality 18-phase 100A VRM
- 10 USB ports, including Thunderbolt 4
- 10 GbE plus Wi-Fi 6E
- Five M.2 slots
- Premium audio w/DAC
- Expensive
Asus' ROG Maximus XIII Extreme and Extreme Glacial are full-featured Z590 motherboards that include robust power delivery, premium audio with a DAC, five M.2 sockets, 10 GbE and integrated Wi-Fi 6E. The Glacial includes a custom waterblock. While pricing is tough to take, the Extreme ($899) and Extreme Glacial ($1499) represent what flagship-class motherboards should be.
